Name: Galvanized Woven Wire Mesh For Filtration And Screening
Brand: HEBEI CITTI MESH CO.,LTD
Price: 200.00 USD
Availability: InStock

Galvanized Woven Wire Mesh For Filtration And Screening

Grande immagine : Galvanized Woven Wire Mesh For Filtration And Screening

Dettagli:

Luogo di origine:	Cina
Marca:	cittimesh

Termini di pagamento e spedizione:

Quantità di ordine minimo:	Negoziabile
Prezzo:	100 usd-300usd
Imballaggi particolari:	Imballaggio in legno
Tempi di consegna:	Dipende dalla quantità di merci
Termini di pagamento:	L/C, T/T

Contatto

Galvanized Woven Wire Mesh For Filtration And Screening

descrizione

Nome del prodotto:

Griglia di filo tessuto galvanizzato

Applicazione:

zanzariere, protezioni di sicurezza, setacci, filtri olio, vibrovagli, filtrazione di liquidi e gas.

Evidenziare:

galvanized woven wire mesh

wire mesh for filtration

woven wire cloth screening

Galvanized woven wire mesh for filtration and screening

Galvanized woven wire mesh is one of the most inexpensive options in window screen and filtration applications. The mesh is coated with zinc to protect it from rust and corrosion. The galvanized wire mesh has corrosion resistance and has a longer service life than plain steel wire mesh.

Typical applications including: window screens, safety guards, sieve grains, oil strainers, vibrating screen, liquid and gas filtration.

Types of Galvanized Woven Wire Mesh

Electro Galvanized (Before Weaving)
Electro Galvanized (After Weaving)
Hot-Dipped Galvanized (Before Weaving)
Hot-Dipped Galvanized (After Weaving)

Mesh count	Wire Dia. (mm)	Opening (mm)
3	1.6	6.87
4	1.2	5.15
5	0.95	4.13
6	0.8	3.43
8	0.7	2.43
10	0.6	1.94
12	0.55	1.56
14	0.14	1.4
16	0.38	1.24
18	0.3	1.11
20	0.27	1
22	0.25	0.9
24	0.23	0.83
26	0.2	0.78
28	0.18	0.73
30	0.15	0.7
35	0.14	0.59
40	0.14	0.5
50	0.12	0.39
60	0.12	0.3
